Technical Specifications:
-
Configuration
13S5P (65 cells)
Nominal Voltage
46.8V (standard 48V system)
Typical Capacity
13.0Ah
Minimum Capacity
12.35Ah
Charge Temperature Range
10°C ~ 45°C
Discharge Temperature Range
-15°C ~ 60°C
Weight
Approx. 3,500g
Frequently Asked Questions (FAQ)
What is the actual voltage and capacity of this battery pack?
The nominal voltage is 46.8V (compatible with standard 48V systems), with a typical capacity of 13.0Ah and a minimum capacity of 12.35Ah. The battery uses 65 cells in a 13S5P configuration.
What type of BMS is included?
The pack comes with a separate-port PCM supporting 25A continuous discharge, 3.2A charge current, NTC temperature sensor, and comprehensive protections. Important: Do not short-circuit P-/C- or charge through the discharge port - otherwise the battery will lose overcharge protection.
Can I use this battery for an e-bike or e-scooter?
Yes. This 48V 13Ah Li-ion battery pack is ideal for electric bicycles, scooters, light EVs, and many industrial applications. Always check your motor controller's voltage and current requirements before installation.
How should I store the battery when not in use?
Store the battery in a cool, dry, and well-ventilated area at 20%–40% of rated capacity. For long-term storage (over 3 months), recharge to 20%–40% capacity every 3 months to prevent over-discharge. Ideal storage temperature is 25±5°C with humidity of 60±15%.
